LT-1WSPTH1N

1-Wire Surveillance earpiece for Airbus Radio TH1N NK06 Connector

This 1-Wire surveillance earpiece is designed for seamless communication in high-demand environments. It features an ergonomic PTT button for ease of use, an acoustic tube for discreet listening, and a noise-cancelling microphone to ensure clear communication even in noisy surroundings. This earpiece is tailored for use with the Airbus Radio TH1N, making it an ideal solution for professionals in law enforcement, security, and other mission-critical roles.

Login to view prices

Additional information

Speaker Specification

Type
Dynamic Speaker

Impedance
200Ω ±15%@1KHz

Sensitivity
110±4dB@1KHz

Frequency Response
100Hz ~ 4.5KHz

Rated Input Power
10mW

Maximum Input Power
300mW

MaximumInput Power 300mW

Microphone Specification

Sensitivity
-38 ±4dB (RL=2.2KΩ, Vs=3.0V DC, 1KHz 0dB=1V/Pa)

Impedance Max
2.2KΩ@1KHz (RL=2.2KΩ)

Frequency Response
20Hz ~ 20KHz

Current Consumption Max
0.5uA (RL=2.2KΩ, Vs=3.0V DC)

Signal-to-Noise Ratio
≥58dB
Max Sound Pressure Level
115dB SPL, 1KHz, THD<5%

Datasheet

Download
