LT-4310SF-1-1-4

4.3-10 Straight Female Connector for 50-33 Flexible RF Cable

The LT-4310SF-1-1/4 is a precision-built 4.3-10 Female Connector designed for 1-1/4″ coaxial cables, offering low passive intermodulation (PIM) and excellent signal integrity. It is ideal for modern telecom applications, including 5G, LTE, and high-frequency RF systems, where compact size, high performance, and low interference are critical. Its advanced design ensures secure and low-loss connectivity in both indoor and outdoor environments, making it a reliable choice for antenna systems, distributed antenna systems (DAS), and base stations.

Login to view prices

Additional information

Material and Plating

Inner Conductor
Tin-Bronze / Silver Plating

Outer Conductor & Body
Tin-Bronze / Silver Plating

Body
Brass / Trimetal Plating

Insulator
TPX

Gasket
Silicon Rubber

Electrical Specifications

Mating Durability
≥500 cycles

Mechanical Shock Test Method
MIL-STD-202, Method 213, Test

Vibration Test Method
MIL-STD-202, Meth. 204, Cond. A

Temperature Range
-45°C to +85°C

RoHS
Compliant

Sealing Class
IP68 24hr, 1m, 20 C

Regulatory Compliance / Certification

ISO 9001:2015
Compliant
