LT-ARREST-NFNF-1-4

N Type Male to N Type Female 1/4λ Arrester

LT-ARREST-NFNF-1/4 is a high-performance RF lightning arrestor featuring N-Female to N-Female connectors with a 1/4 wavelength shorting stub design. It is engineered to protect sensitive RF
equipment from lightning strikes and electrical surges, ensuring system reliability and extended equipment life. The LT-ARREST-NFNF-1/4 provides a robust surge protection solution for communication systems, base stations, and RF transmission lines.

Login to view prices

Additional information

Material and Plating

Inner Conductor Plug
Brass/Silver Plating

Inner Conductor Jack
Tin Bronze/Silver Plating

Body & Outer Conductor
Brass/Trimetal (Cu-Sn-Zn) Plating

Insulator
PTFE/TPX

Gasket
Silicon Rubber

Nut
Brass/Nickel Plating

Standard Component
Stainless

Electrical Specifications

Characteristic Impedance
50 Ohm

Frequency Range
700~2700 MHz

Center Contact
≤1.00 mΩ

Outer Contact Resistance
≤0.25 mΩ

Maximum Surge
30 kA(8/20us)

Residual Pulse Voltage
≤100 V(8/20us)

Average Power
@900MHz
600 W

Insertion Loss
@700-2700MHz
≤0.20 dB

VSWR
@700-2700MHz
≤1.20

PIM (2*43dBm)
@1800MHz
≤-150 dBc

Environmental & Mechanical Specifications

Mating Durability
≥500 cycles

Operating Temperature
-45°C to +85°C

Degree of Protection
IP68 24hr, 1m, 20

RoHS
Compliant

Regulatory Compliance / Certification

ISO 9001:2015
Compliant

Datasheet

Download
