LT-NF-1/2L
N-Female Connector for 1/2” Cable
The LT-NF-1/2L is a reliable N-Type Female Connector designed for 1/2″ Superflex coaxial cables, offering stable, low-loss signal transmission in a compact and robust form. It is widely used in wireless infrastructure, broadcast systems, and RF transmission lines, particularly where flexibility and durability are required. This connector ensures secure connections with low VSWR, making it ideal for indoor and outdoor telecom applications, especially in systems requiring frequent bends and routing in tight spaces.
Login to view prices
Additional information
| Characteristic Impedance | 50Ω |
|---|---|
| Cut-Off Frequency | ≤ 18 GHz |
| Shielding Efficiency | ≥ 115 dB |
| Inner Conductor Contact Resistance | ≤ 0.8 mΩ |
| Outer Conductor Contact Resistance | ≤ 0.25 mΩ |
| Third-Order Intermodulation (IM3) | ≤ -155 dBc |
| Insertion Loss | ≤ 0.10 dB |
| Insulation Resistance | ≥ 5000 mΩ |
| Dielectric Strength | 2500 V |
| VSWR | 0.8 – 1.0 GHz ≤ 1.08 |
| Inner Conductor | Pin / Socket |
| Gasket | Silicon Rubber |
| Operating Temperature Range | -65 °C to +165 °C |
