LT-PL259M-RG214

LT-PL259M-RG214

PL295 Straight Male for RG214

The Lamatel LT-PL259M-RG214 is a PL259 male connector designed for RG214 coaxial cables. This connector provides a secure, threaded connection ideal for high-frequency RF applications. Commonly used in amateur radio, communications, and broadcast systems, it ensures reliable signal transmission with minimal interference.

Login to view prices

Additional information

Material and Plating

Center Contact
Brass / Gold Plating

Outer Contact & Body
Brass / Nickel Plating

Dielectric
PTFE

Gasket
Silicon Rubber
Electrical Characteristics

Characteristics Impedance
50 Ohm

Frequency Range
DC~11GHz

Insulation Resistance
≥5000MΩ

Center Contact Resistance
≤1.0 mΩ

Outer Contact Resistance
≤0.4 mΩ

Dielectric Strength
2500V rms (AC)

Working Voltage
1000V rms

Insertion Loss
≤0.15dB@3GHz

VSWR
≤1.1@DC~1.0GHz
≤1.2@DC~3.0GHz
Environmental and Mechanical Specifications

Durability (Matings)
≥500 cycles

Mechanical Shock Test Method
MIL-STD-202, Method 213, Test Condition G

Vibration Test Method
MIL-STD-202, Meth. 204, Cond. B

The Size of Crimp Tool
0.429 inch

Suitable Cables
RG214

Temperature Range
-65°C to +165°C

RoHS
Compliant

Datasheet

Download
