LT-SWCP4T
Terminated Coaxial Switch
The LT-SWCP4T is a high-performance RF coaxial switch designed for applications requiring wide bandwidth and precision. Supporting frequencies from DC up to 18GHz, it delivers low insertion loss, high isolation, and exceptional repeatability. Ideal for use in SATCOM, aviation, military and commercial telecom systems, medical imaging, and automated test equipment (ATE), this switch ensures reliable signal routing in demanding environments.
Login to view prices
Additional information
| Frequency Range | DC-18 GHz |
|---|---|
| Input Power | 1 (CW) |
| Switching Time | 20ms |
| Repeatability | 0.05 (dBKMax) |
| Operating Life | 2M cycles |
| Connector Type | SMA(f) |
| DC Drive Voltage | +20-+28 |
| DC Drive Current | 200mA |
| SWR (Max) | 1.1 (DC~4GHz) |
| Insertion Loss dB (Max) | 0.4 (4~12.4GHz) |
| Isolation (dB) (Min) | 80 (DC~4GHz) |
